Ultra-Short Pulses with High Power
The LDP-AV 16N45-40 electronics have 16 separate channels that can be equipped with a total current of 640 A; therefore, an output current of up to 40 A is available in each channel. Each of these channels can be controlled independently and sequentially. This makes the driver ideal for multi-channel applications. The duration of the individual pulses is set by the manufacturer according to customer specifications.
Laser powers of more than 650 W can be controlled with the LDP-AV 1N50-450. The electronics are particularly compact and offer output currents of 450 A and a power density of 1.71 W/mm² at a pulse duration of 5 ns. Other pulse durations can also be permanently set. Laser diodes and other emitters can be mounted directly to the circuit board of the driver to avoid interference from induction currents.
Further product information:
Driver Modules and Electronics for the Operation of Pulsed Laser Diodes
