New DispensingCell DC803: Highest performance in series production

The encapsulation of varying components, changing capacities or lack of space on the production shop floor: The demands placed on adhesive bonding, sealing and potting processes are becoming increasingly individual. Against this background, the possibility of efficient and economical adaptation of the dispensing system plays a decisive role.

With the DispensingCell DC803 a new, powerful multifunctional cell is available for demanding dispensing applications. This system can be used to cover numerous tasks, ranging from potting and the application of liquid seals and adhesives to the sealing of sensitive electronic surfaces. The cell is the further development of the reliable CNCell from Scheugenpflug and has been tailored even more precisely to the requirements of industrial series production.

High flexibility for medium to large quantities

The DispensingCell DC803 has been designed especially for productions with medium to high quantities. The servo motor technology and the high-performance axis system allow high traversing speeds and thus short cycle times for matrix and bead applications. The plug-and-produce principle ensures fast commissioning.

The new multifunctional cell is based on standardized modules that are individually assembled according to customer specifications. It can be combined with all Scheugenpflug dispensers and material preparation and/or feeding units. This allows for a very individual and customer-specific system planning.

The scope of features and degree of automation of the DispensingCell DC803 can also be flexibly adapted: In addition to being used as a stand-alone system, its inline variant can be integrated directly into existing production lines. The cell can also be equipped with additional equipment such as handling systems or joining technology. In order to ensure reliable dispensing results numerous options for process monitoring are available.

All relevant data constantly in view

The integrated control unit UViS₅ allows for simple and intuitive cell operation. Users have a continuous overview of all relevant process data on a 15.6" multi-touch display. Predefined functions for the most common dispensing tasks and a quick access to relevant process parameters ensure greater efficiency. The optional UPiC₅ programming tool complements and extends the UViS₅ operating software. With this tool users can quickly and easily create complex dispensing programs.
