CONTROL-KNOBS – Modern tuning knobs with a high level of operating comfort
The modern CONTROL-KNOBS are designed for user-friendly utilisation and consist of hard and soft plastic components: knob body made of high-quality PC (UL 94 HB), with a soft touch TPE outer shell with a functional grooved appearance. Thanks to the soft-touch material, the new tuning knobs offer high grip qualities with an anti-slip effect. Installation of the CONTROL-KNOBS is effected using collets, which guarantee a secure fit on the spindle and are ideally suited for rotary potentiometers/pulse encoders with round shaft ends in accordance with DIN 41 591. For final assembly, a cover made of PA 6 (UL94) is mounted on the basic body. The CONTROL-KNOBS are available in the standard colours nero and volcano in the following sizes:
- ø 36 mm, with hole 6 mm and 1/4" (6.35 mm)
- ø 46 mm, with hole 6 mm and 1/4" (6.35 mm)
Both sizes are available with/without a pointer line on the side for fine scaling. As a visual highlight, optional illumination gives impressive emphasis. The tuning knobs can be fitted with energy-saving SMD LED technology to provide individual lighting results. In this version, the basic body of the knob is not traffic white, but is made of translucent material. This gives the following illumination options:
- translucent optic ring on the top surface
- translucent optic ring on the top surface with pointer line on the side
To illuminate the ring, the base available in the range of accessories is required, together with the LED lighting kit (RGB backlight). Applications include measuring and control engineering, medical field and laboratory technology, the smart factory, communication and much more. To adapt the knobs to special customer requirements, they can be modified by means of printing or laser marking on the top surface/cover.
Gehäuse und Drehknöpfe
OKW bietet formschöne, ergonomisch günstige Standardgehäuse und Drehknöpfe aus Kunststoff und Aluminium für die OEM Elektro- und Elektronik-Industrie. Abgestimmt auf die jeweilige Kundenanwendung ergänzen funktionale Zubehörteile, eine EMV Aluminiumbeschichtung sowie elektromechanische Komponenten die Standard-Produkte auf vielfältige Weise. Bei Bedarf liefern wir die Gehäuse und Drehknöpfe einbaufertig – auch in kleinen Stückzahlen – nach Ihren Anforderungen und Wünschen.
Standard Electronic Enclosures and Potentiometer Tuning Knobs
Smart ergonomic standard enclosures and potentiometer knobs for OEM electronics. OKW’s award-winning aesthetic designs will transform your products. View our huge range of plastic and aluminium cases as well as tuning knobs below. Our designs are highly versatile so you can find the cases you need quickly and easily. Products also include membrane keyboards; contacts and connections; EMC shielding; compatible parts (batteries, displays, emitters, potentiometers, screws etc.). All OKW enclosures can be customised to your precise requirements – even in low volumes – ready for your PCBs.
