Fast and flexible motion control software development: Elmo Motion Composer2, SIL (Software in the Loop) tool available for Platinum series intelligent servo drives
The integration with the Real Time Workshop allows access to measurement devices such as inertial sensors, gyros and IMUs as well as a host of machine control I/O devices, hardware components, and sub-systems from a wide range of manufacturers. Users can develop their preferred communication protocols over serial links in real-time and kinematic transformations are easily designed and implemented.
Elmo Motion’s Platinum series covers four intelligent drive designs with single-axis as well as 4-axis servo capability. Through the range, typical continuous power levels to 2 kW and qualitative power levels to 5.0 kW are available (up to 22 kW coming soon). All Platinum series drives feature industry leading processing capability channelled through EtherCAT with cycling down to 100 microseconds. These impressive cycling rates provide the basis for unparalleled motion synchronisation and the potential for Software in the Loop processing provides a platform for extremely demanding high speed and high throughput motion-centric automation applications across industry, research, and defence. As well as their SIL capability, Platinum series drives also offer comprehensive functional Safety and FSoE certification. For straightforward application development, ELMO’s EASII Application Studio software also manages EtherCAT configuration, motion configuration, drive tuning, parameter recording, monitoring, and much more.
With several years’ experience with Elmo Motion and supported by its own in-house design and build capability, Heason supplies and supports Elmo’s full range of servo drives and controls as separate motion components or as part of custom-designed motion systems complete with positioning and drive transmission mechanics. . For further information, please visit www.heason.com, email sales@heason.com or call +44 (0)1403 792 300.
The Slinfold – West Sussex based motion specialist combines its own manufacturing and design & build systems integration expertise with motion products, components and systems from a small but select group of globally recognised distribution partners. Heason Technology’s comprehensive range includes servo and stepper motors with associated drives and motion controls; linear and rotary positioning mechanics; linear and rotary encoders; ceramic servo motors and positioning stages; high precision gearboxes; rotary actuators and slip ring assemblies. Customised system solutions include automated motion axes, specialised position controls and bespoke positioning mechanics.
