New Out-of-Liquid mass flow module

IST AG launches new Out-of-Liquid mass flow module. Accurate, robust and ready-to-use: The compact and corrosion-resistant module is suitable for flow monitoring and leakage detection of various liquids.

Suitable for a wide variety of applications from cooling circuits, dosing pumps, white goods, CIP systems for food industry, agricultural machines, industrial wet vacuum cleaners, to gear oil used in metalworking and mining, IST AG’s new thermal OOL mass flow meter can be easily integrated into new or existing industrial systems.

Its robust housing contains IST AG’s well-established OOL technology that makes the corrosion resistant thermal mass flow ideal for flow monitoring of aqueous solutions, alcohols and oils, including aggressive liquids.

IST AG’s OOL mass flow meter comes as a plug&play solution factory-calibrated for DI-water at a great price-performance ratio. Its mass flow and temperature measurements are transmitted via I2C digital outputs. It is mechanically robust, highly accurate, has a dynamic range and is sensitive at low flow rated with no pressure loss. Further features include:

Calibration range:                          1-200 kg/h
Temperature compensated:             from +5 °C to +50 °C
Fluidic connection:                          tubing with 4 mm inner diameter
Flow channel inner dimensions:       3.7 mm
Single wetted material:                   stainless steel 1.4301
Response time t63:                         0.5 seconds

With the OOL mass flow meter IST AG is meeting a frequent demand of their customers to provide an active flow sensor module. It is the ideal product for customers looking for a ready-made digital flow sensor. Thank to its factory calibration it needs no assembly, it can be plugged into an application and is ready to monitor flow and temperature.

Shop the Out-of-Liquid Mass flow module in our Webshop.

Über die Innovative Sensor Technology IST AG

Innovative Sensor Technology IST AG is one of the global leaders in micro system technology, services and solutions for industrial measurement applications. The company employs approx. 400 personnel across the globe.

IST AG is a manufacturer and partner for physical, chemical and biological sensors. Its product range contains thin-film platinum and nickel RTD temperature sensors, capacitive humidity sensors, thermal mass flow sensors, conductivity and biosensors. IST AG also manufactures a broad portfolio of calibrated humidity modules. Additionally, a highly qualified technical team offers consulting, development and production of challenging customer requests in the field of micro system technology.

The wide product range is the choice of many renowned end customers and OEMs in their fields. As a result, IST AG sensors are found in measuring instruments for various applications, such as HVAC, automation, appliance, medical, test and measurement, aerospace, bio measurement and process control and many more.

Founded in 1991, Innovative Sensor Technology is headquartered in Ebnat-Kappel, Switzerland in the mountain region of Toggenburg. In 2005, Innovative Sensor Technology became part of the Endress+Hauser Group, headquartered in Reinach, Switzerland. The Endress+Hauser Group is among the global leaders in measuring instruments, services and solutions for industrial process engineering.

For further information, please visit www.ist-ag.com
