Submersible tilt sensor provides high-resolution, large-angle position feedback for harsh-industrial and marine applications

Particularly suited to severe industrial and marine-based applications such as crane & hoist, construction machinery or drilling platforms, although competitively priced for use on less arduous measurement tasks, the S613’s 10 g shock and 40 g vibration rating (IEC 68-2) contributes to exceptional reliability over an operating temperature range of -20°C to +85°C. Positek’s ASIC control technology interprets the absolute position of embedded inductive coils to provide a proportional, high-bandwidth DC analogue output signal with essentially infinite resolution. In comparison to alternative LVDT/RVDT and magneto-strictive sensors, no further signal condition is required, and furthermore the space-efficient Positek sensor has a much smaller coil design, a superior stroke-to-length ratio and does not require the use of expensive magnetic materials. In this way, Positek sensors cost-effectively offers the simplicity of potentiometer-based sensors while its non-contacting LVDT principle, developed and patented by Positek, provides exceptionally long life (MTBF – 350,000 hrs at 40°C Gf).

The compact S613 features a robust and fully sealed 35 mm diameter by 44 mm long stainlesssteel housing. An integral 60 mm diameter mounting flange with two wide mounting slots and a choice of input shafts facilitates straightforward mounting. A wide choice of output options include 0.5 … 4.5 V ratiometric from a 5V supply, several buffered DC voltage outputs and 2- or 3-wire, 4…20 mA current outputs from a nominal 24V DC input. Electrical connection is via a Pg7 gland and cable arrangement with customer specified length up to 50 cm.

Positek Limited is an ISO9001:2015 designer and manufacturer producing a wide range of linear, rotary and tilt position sensors for use across demanding applications in industries as diverse as oil & gas, mining, marine, agriculture, construction, off-road, motorsports, and more. Several product lines have optional ATEX, IECEx and CSA certification. A complete specification for the S613 tilt sensor is available on Positek’s website along with comprehensive information across its broad range of standard and customised products at www.positek.com with further information from sales@positek.com or by calling +44(0)1242 820027.
