Congestion-free data and video transmission under harsh environmental conditions with 12V, 24V or 48V DC

Sufficient bandwidth is required for the transmission of high-resolution video signals. If more than one camera is connected to one switch, a gigabit Ethernet uplink (1GbE) to the central processing would become a bottleneck. The 10 Gigabit Ethernet (10GbE) uplink port for SFP+ modules allows, caused by the high bandwidth, the transmission of all Gigabit Ethernet RJ-45 ports simultaneous without delay. Moreover the transmission rate can be increased by using Jumbo Frames.

The Switch provides operating current for end devices by Power over Ethernet (PoE+ up to 30W /port according to IEEE 802.3at standard or up to 15.6W /port according to IEEE 802.3af standard). The device can alternatively be supplied with 12V DC (90W budget) or 24V DC (180W budget). From a voltage of 36V DC, the entire PoE budget of 240W is available.

The dimensions of the housing (WxHxD 54x142x99mm) enable integration into tight environments. The operating temperature from -40°C up to +60°C allows operation even in non-air-conditioned areas. This is a robust system, equipped with high EFT and ESD protection, polarity reverse protection and overload current protection. The device may be powered redundantly.

The standard equipment with fastening elements for wall mounting and DIN rail mounting allows the use of the Switch without any further accessories in most environments.

Item reference:
129632200   Industrial Ethernet switch 2x 10GbE SFP+ and 8x GbE RJ-45 PoE+
12233911    10 Gigabit Ethernet SFP+ singlemode 1310nm 10km DDM -40..+85°C
