Sweden’s Viaplay produces with Lawo AoIP Infrastructure

The Viaplay media and entertainment company, headquartered in Stockholm, offers transmissions of diverse programs such as sports, comedy shows and movies. After inking a new contract with production companies Ekstraklasa Live Park and the ATM Group, and with their recent expansion of services beyond the Nordic region into the Baltics, the Netherlands, and Poland, Viaplay undertook a major technical upgrade to ensure the reliability of service demanded by simultaneous transmission of many separate sporting events.

LP Systems, Lawo’s partner in Poland, were appointed to implement the audio portion of Viaplay’s studio update. “The project is designed as a fully IP-based infrastructure”, says Artur Jóźwik, Sales and Support Engineer. The project’s scope included two new studios with separate control rooms for audio and video, as well as twelve sports commentator booths with six separate small audio control rooms. The massive technical upgrade was performed during June and July 2022, to be ready in advance of fall sporting event coverage.

For the main audio control rooms, two Lawo mc²36 all-in-one production consoles where chosen. Compact yet flexible and powered by Lawo A__UHD core technology, mc²36 consoles can be sized from 16 to 48 faders and feature intuitive guided workflows, and the A__UHD cores each provide 256 DSP channels, 48kHz and 96kHz operation, and 864 channels of I/O capacity. IP-native with support for all relevant standards, they also feature redundant power supplies and ST2022-7 ‘hitless merge’ network link redundancy demanded by live broadcast operations.

diamond broadcast desks were installed in each of the six audio control rooms. The newest Lawo broadcast console, diamond’s flexible concept scales from 2 to 60 physical faders and features an innovative Virtual Extension touchscreen control and information option. The diamonds are powered by three Power Core engines equipped with MAX licenses; these IP-native devices featured built-in RAVENNA and MADI interfaces plus expansion slots for analog, digital and DANTE interface cards, plus 96 DSP channels and 80 summing busses.

“All microphone inputs, sums, AUX lines and other signals are transmitted as RAVENNA / AES67 streams; only the speaker connections remained analogue,” says LP Systems’ Jóźwik. “It’s a very flexible solution that enables Viaplay to combine any studio with any control room at any time. Everything works together seamlessly, without any additional routing needed.”

More flexibility is provided by Lawo VisTool software, which allows creation of customizable, context-sensitive mixing tools for multi-touch displays. All of Viaplay’s diamond consoles are equipped with dedicated all-in-one PCs running VisTool, which power their Virtual Extension touchscreens. This enables operators to instantly visualize EQ curves, compression settings, DSP functions, routing setups, and even integrate control of third party software and devices.

All IP-native Lawo devices are connected and managed within the network by the HOME management platform for IP-based media infrastructures, using web interfaces with standard browsers. The RAVENNA / AES67 audio network is underpinned by Artel Quarra switches, which are configured to provide a fully redundant networking environment. Integration with video systems is done using DirectOut Prodigy.MP processors in mirror mode for full system redundancy. These devices convert RAVENNA signals to MADI and vice versa, and help facilitate final DSP processing.

“Working closely with ATM Group’s engineers, we achieved all of Viaplay’s goals and desired system functionalities,” says Bartosz Stawiarski-Lietzau, Sales and Support Engineer of LP Systems. “Along with the VisTool controls in the audio control rooms, an additional VisTool computer is installed in the Master Control Room for quick access by the engineer. All of the Power Core units and diamond surfaces can be monitored, diagnosed and controlled there, with audio streams monitored using Lawo RƎLAY AoIP Stream Monitor software.”

The ability to tailor Lawo solutions to their specific needs was extremely important to Viaplay, notes Stawiarski-Lietzau. “Like all complex broadcast operations, Viaplay has highly refined operational requirements. To meet these requirements, we needed to adjust the functions of mixing surface keys, customize control screens and match system functionality to workflow expectations. Lawo, with their intense focus on flexible, customizable solutions, made it easy for us to meet – and exceed – customer expectations.”

About LP Systems

LP Systems in Warsaw is a team of ambitious engineers specializing in audio video technology and deeply rooted in the radio and television broadcasting community. Lawo partner in Poland since 2016, LP Systems offers Polish customers access to the latest technological developments in television, radio, production systems, orchestration systems and other aspects of the broadcasting production process. Primary focus is set on professional consulting and training, first-class technical support and efficient service. Thanks to the team’s many years of experience in radio and TV as well as large media productions, LP Systems is capable of quickly identifying the client’s needs or pointing out critical aspects in the system or in the process in question. Reliability, competence and honesty combined with openness to tasks are the foundation of the team’s success. LP Systems was one of the first in Poland to promote IP solutions so widely and is one of the pioneers in large-scale deployments of IP technology (ST 2110/ST2022) for TV production.

About Viaplay

Sweden’s Viaplay is a provider of audiovisual content distribution services intended to help transform the world of entertainment. The company offers unlimited access to live sports, the latest international TV releases, original drama, all-time classics, film premieres as well as kid’s most-loved animation and series through individual purchases, rent or via subscription with or without a lock-in period in the form of various software packages, enabling viewers to have access and enjoy to a number of shows.
