Protection against electric shock according to IEC 60601-1
IEC 60601-1 requires manufacturers of medical electrical equipment and systems to ensure that they function in an all-around safe and reliable manner. On the one hand, the requirements can be solved by selecting special electronic components and integrating them into the power supply, control or signal generator of the device. On the other hand, the standard can be implemented by the connector, which already takes into account the higher clearance and creepage distances in the connector design.
The implementation via the power supply or the subsequent electronics seems easier at first moment. However, specially certified components must be used that meet the increased safety requirements. This involves a great deal of work for the medical device manufacturer in setting up the electronics and the associated documentation. As a purely mechanical solution, the plug-in connection offers advantages in that the clearance and creepage distances are ensured via the design. There is no dependence on the service life of the electronic components. The mechanics remain unchanged and are permanently reliable. In this way, compliance with IEC 60601-1 facilitates approval of the medical device and also saves time during product launch.
ODU connectors can be used in medical electrical equipment and systems to transmit signals, high current, high voltage, RF signals (coax), medical gases and fluids, data rates, and light waves. ODU offers IEC 60601-1 compliant circular connectors available in either a plastic (ODU MEDI-SNAP®) or a rugged metal (ODU MINI-SNAP®) housing. The ODU MINI-SNAP® is particularly well suited for applications with higher mechanical loads or extended electrical shielding requirements. In the case of the plastic series, ODU MEDI-SNAP®, the advantages are u.a. in the lower weight, touch protection and the variety of possible color combinations. This allows safe and intuitive use and avoids getting stuck in the wrong place due to the color assignment. The ODU connector portfolio is rounded off with optional cable assembly, u.a. with silicone overmolding.
Decades of experience in the medical industry combined with state-of-the-art technology ensure we can develop your connectors to perfection. Whether in diagnostics, therapy, hybrid operating rooms or patient monitoring. ODU connectors stand for consistent failure protection and reliability in everyday medical use. Our connectors, cables, and housings are characterized by extreme temperature and chemical resistance – and guarantee reliable tightness, including in compliance with high protection classes.
ODU Group: global representation with perfect connections
The ODU Group is one of the world’s leading suppliers of connector systems, employing 2,500 people around the world. In addition to its company headquarters in Muehldorf a. Inn (Germany), ODU also has an international distribution network and production sites in Sibiu/Romania, Shanghai/China, and Tijuana/Mexico. ODU combines all relevant areas of expertise and key technologies including design and development, machine tooling and special machine construction, injection, stamping, turning, surface technology, assembly and cable assembly. The ODU Group sells its products globally through its sales offices in China, Denmark, France, Germany, Hong Kong, Italy, Japan, Korea, Romania, Sweden, UK and the US, as well as through numerous international sales partners. ODU connectors ensure a reliable transmission of power, signals, data and media for a variety of demanding applications including medical technology, military and security, automotive, industrial electronics, and test and measurement.
