The right cleaning process ensures product quality and cost effectiveness

From machine and plant engineering, electrical and power engineering to connecting elements, the so-called general industry contains a multitude of sectors. In these industry sectors, components of the most diverse materials like metals, plastics, ceramic and composite materials are manufactured and processed using very different manufacturing technologies. Products include, for example, cast and machined parts, stamped, bent, pressed and deep-drawn parts, hydraulic parts and, more and more, additively manufactured components. Although the parts are manifold, they have one thing in common: to ensure the quality of downstream processes such as machining, heat treatment, coating, bonding and assembly and to guarantee lasting functionality, they necessitate cleanliness levels in line with requirements. In many areas, ever higher requirements concerning particulate and film-type cleanliness must be met. And there there are often added challenges such as high throughput rates and weights, a strongly varying range of parts to be cleaned, short delivery times and also small margins in some cases.

Adapting cleaning processes to tasks on hand

This means there are different requirements for part cleaning. As supplier of complete future-oriented, flexible and energy-efficient solutions for industrial parts cleaning, Ecoclean covers the complete range of wet-chemical procedures. Cleaning processes and systems for batch or single-part cleaning can be optimally adapted to the respective specifications. To do so the following factors have to be taken into consideration: Material, size, geometry and weight of the part, type and quantity of contaminants, downstream process and the resulting cleanliness specifications and throughput requirements. On this basis it can be determined whether the contaminants can be removed most effectively with a water-based detergent, an environment-friendly solvent or a modified alcohol with lipophilic and hydrophilic properties. What is more, this information enables engineers to define the best suited process and drying technology.

A matching process technology minimizes cleaning cost

In order to minimize the cost per cleaned part, it is necessary that the existing cleanliness specification is not only reliable, but also quickly reached. Therefore the systems are equipped with various application-specific treatment technologies such as spray, high-pressure, immersion, ultrasonic and plasma cleaning, vapour decreasing, injection flood washing, deburring, pulsated pressure cleaning (PPC) as well as a passivation/preservation process as required.

By combining these cleaning procedures, the cleaning result and duration for the specific parts can be influenced in a pinpointed manner. The PPC procedure in combination with an aqueous or solvent-based immersion cleaning for example, reliably and quickly removes contaminations from small cavities. In case of complex and bulk parts, spray processes and injection flood washing with adjustable nozzles between 10 and 16 bar also deliver markedly improved cleaning results and shorter process times in solvent cleaning processes.

Quality and cost can be optimized by combining processes that formerly required several machines in one single cleaning system. Among them are chamber machines designed for solvent-based or aqueous batch cleaning with a subsequent low-pressure plasma process. Among other things, this method effectively and efficiently prepares the part surface for a subsequent coating or bonding. Ecoclean’s extensive product range also offers the respective solutions for pinpointed deburring and cleaning of single parts, for example hydraulic and motor components in one system.

Dry-cleaning – selective or whole surfaces

Cleaning tasks also change along with changing manufacturing and joining technologies. The focus lies more and more on dry-cleaning processes, be it for removing film-type contaminations from joint surfaces in a pinpointed manner, cleaning electronic components and assemblies, removing powder residues from additively manufactured components or cleaning integrated in assembly. For this and many more applications, the equipment manufacturer has developed a special toolbox for cleaning processes with atmospheric pressure plasma, laser, CO₂ snow, conditioned vacuum air as well as saturated and dry water vapour. Depending on the specific application, these ‚tools‘ too are applied alone or combined.

This extensive portfolio of cleaning solutions is supplemented by Technology Centres around the world. They perform tests with original soiled parts under conditions similar to production for all the different tasks existing in part cleaning.
