74 Voice-Acoustic Loudspeakers for Hyundai Elevator in South Korea

The South Korean audio specialist YNC Solution, Voice-Acoustic’s exclusive distribution partner since the end of October 2016, has stood for competence and customer satisfaction for more than 15 years. Many successfully completed audio installations in recent years distinguish the YNC Solution team as a general service provider (from planning to commissioning). This project involved providing a suitable sound system for an auditorium for 400 people, a banquet hall, 6 meeting and seminar rooms as well as a company restaurant. A total of 74 Voice-Acoustic loudspeakers and 16 HDSP system amplifiers were installed.

"For the approx. 560m² auditorium, the constant curvature line array Ikarray-8 from Voice-Acoustic was the first choice for us”, says Terrie Lee, President of YNC Solution. " With an L/R setup of 2x 3 Ikarray-8 (1x 15° + 2x 5°) and a centre cluster with 1x Ikarray-8 (15°) a maximum SPL (broadband) of 120db to 121db was simulated with EASE. In the low frequency range, the system, which was designed for a width of 20 metres and a depth of 28 metres, was extended by 2x 2 Paveosub-115. A total of 4x Score-5 were used as stage monitors and 12x Alea-4 as surround speakers. The entire speaker system is driven by 2x HDSP-6A, 1x HDSP-4A, 2x HDSP-0.4A (or 14 power amp channels)."

Voice-Acoustic equipment list for Hyundai Elevator project:

1. Auditorium

07x Ikarray-8

04x Paveosub-115

04x Score-5

12x Alea-4

02x HDSP-6A

01x HDSP-4A

02x HDSP-0.4A

2. Large Meeting Room

04x LA-Stick 4×4

01x Paveosub-112

06x Alea-4

01x HDSP-4A

01x HDSP0.2A

3. Seminar Room

02x Score-5

01x HDSP-0.2A

4. Training Rooms (1-4)

08x LA-Stick 4×4

04x HDSP-0.2A

5. Banquette Hall

02x Score-5

02x Paveosub-112

06x Alea-4

01x HDSP-4A

01x HDSP-0.2A

6. Restaurant

02x Score-5

02x Paveosub-112

12x Alea-4

02x HDSP-4A
