LAB 2.0 – Maximizing the indication module with minimized energy consumption

In this context, the display modules are the simplest form of status indication. In 2023, EES will launch a new generation of the proven LAB series, where LAB stands for LED display module. The new generation turns the previously available variants upside down and concentrates them in one display module. Therefore the number of different sizes increases, which are now not only available in 8 or 16 channels, but also in 24, 32, 40 and 48 signal inputs. In the future, there will be only one variant per number of signal inputs, which greatly simplifies and optimizes the ordering process, stock-keeping and usability.

The LED display is the distinctive feature of the indication module, and the LED colors can still be changed by the customer. There are 6 colors available, so the exchange of single LEDs or whole rows can be done quickly according to the application.
The LED colors are colored via lightpipes and can be purchased as accessories.
Another new feature is that each LAB 2.0 contains a signal relay that can be used as a collective signal to advance technology. It can be set group-wise whether an activation of the alarm is supposed to take place on the collective alarm relay. Likewise an inversion of the relay can take place and the alarm inputs can also be switched over between normally and normally closed principle. The settings are made via a DIP switch.

An integrated push button and external function input for the lamp test complete the range of functions.

The power supply of the device is done by a wide range power supply which is suitable for the voltage range between 24V – 230V AC and DC. The signal inputs are also activated by a wide range power supply, which is also between 24-230V AC and DC.
Narrower signaling thresholds can also be obtained as an option on a customer-specific basis.
Another new feature is that the signal wiring is done via plug-in screw terminals, which simplifies the installation.

During development, EES also focused on energy consumption. In total, the power consumption with 48 illuminated LEDs and activated signal relays is only approx. 1 watt.
The protection class of the device is now IP54 as a standard, so that no additional hood is required to achieve a higher degree of protection.

In summary, EES hereby offers the maximization of the classic indication module with 96mm in height, available in 96mm width for 8 or 16 inputs, 192mm for 24 or 32 inputs and finally in 287mm width for 40 or 48 inputs. All features are on board as standard and can be customized in the easiest way. List prices could also be optimized for the new LAB 2.0 due to fully automated manufacturing. Available from July 2023.
