P6CU-0505ELF – 1-Watt DC/DC lightweight with many possibilities
With only 2.3g and a case dimension of 19.3 x 6.1 x 9.9 mm, the P6CU-0505ELF is a cost-effective lightweight with little space requirement. This all-rounder is suitable for operating temperatures from -40°C to +100°C.
The converter is available with dual output (P6CU-xxxxZLF) as well as in DIP package version. In addition to the 5V of the presented P6CU-0505ELF, the corresponding product series P6CU-xxxxELF also offers input voltages of 3.3V/12V/15V and 24V. Available output voltages are 5V/12V/15V and 24V.
The standard isolation is 1kV, but can be equipped up to 6kV on request. Thus, this lightweight can always be adapted to the desired requirements due to its possible variations.
If you have any questions, please do not hesitate to contact our team!
