Versatile IB837 3.5-inch SBC Supports Intel Celeron N & J Series Processors
At the heart of the IB837 is the onboard Intel® Celeron® N & J series (formerly Elkhart Lake) processor, offering a good balance of performance and power efficiency. With support for up to 16GB of DDR4-3200 SO-DIMM memory, the SBC ensures smooth multitasking and efficient operation, delivering exceptional performance while consuming minimal power for applications requiring a compact form factor.
The IB837 is equipped with a comprehensive selection of I/O ports to facilitate seamless integration with various peripherals and devices. It features one DisplayPort and two dual-channel LVDS interfaces, enabling flexible display configurations for enhanced visual experiences. Additionally, the board offers two I226V PCI-E 2.5G LAN, four USB 3.1, two USB 2.0, and one SATA III port, which can be shared with the M.2 B-key slot, allowing for flexible storage options.
The IB837 incorporates two M.2 sockets (E-key & B-key) and one full-size Mini PCI-E slot, providing versatile expansion capabilities for wireless communication modules, storage devices, and other expansion cards. The inclusion of essential features such as 12V DC-in power input, extended temperature range, a watchdog timer, digital I/O, fTPM, and mSATA further enhances the functionality of the platform. For more information, please visit www.ibase.com.tw or contact sales@ibase.com.tw.
IB837 FEATURES:
- Onboard Intel® Celeron® N & J series processor
- 1x DDR4-3200 SO-DIMM, Max. 16GB
- Supports 1x DisplayPort & 2x dual channel LVDS
- 2x I226V PCI-E 2.5G LAN, 6x COM ports
- 4x USB 3.1, 2x USB 2.0, 1x SATA III (shared with M/2 B-key)
- 2x M.2 sockets (E-key & B-key), 1x Mini PCI-E slot (full-size)
- Watchdog timer, Digital I/O, fTPM, mSATA, 12V only DC-in
IBASE Technology (TPEx: 8050) specializes in the design and manufacture of robust industrial PC products, delivering high-quality products and excellent service since its establishment in 2000. We carry out manufacturing and quality control at our own facilities in Taiwan that are ISO 9001, ISO 13485, and ISO 14001 certified. We also provide ODM/JDM services, tailoring products to customers‘ requirements. Current product offerings comprise x86- and RISC-based industrial motherboards, embedded systems, panel PCs, digital signage players, and network appliances for applications in the AIoT, automation, smart retail, transportation, networking, and medical sectors. For more information, please visit www.ibase.com.tw.
IBASE is a Titanium member of the Intel® Partner Alliance that offers exclusive resources for AI, cloud, high performance computing, and other solution areas to help plan, build, and deliver more customer value. As an Intel-recognized top-tier partner, IBASE works together with Intel and the ecosystem to deliver the most advanced products and solutions to our customers.
