Compact and durable embedded PC for the smart factory
Designed to meet the demands of smart factory applications, the BOXER-6406-ADN boasts a variety of features that make it a particularly sturdy choice for industrial projects. Notably, its operating temperature stands out, ranging from -20°C to 60°C. Furthermore, the system supports a wide input voltage range of 9V to 36V, including over/under voltage protection as well as short-circuit protection. To enhance its durability, the system is equipped with IEC 68-2-27 shock resistance and advanced anti-vibration capabilities. Lockable I/O connectors have also been integrated to protect against wear and tear. With dimensions of only 186 mm x 104.6 mm x 49.1 mm, the compact housing of the BOXER-6406-ADN can be conveniently wall-mounted. The system relies solely on passive cooling mechanisms and eschews fan-based cooling systems to prevent the accumulation of contaminants in industrial environments.
The BOXER-6406-ADN is available in various variants, each equipped with Intel® N200, N50, or Intel® Atom® x7211E processors. This selection was made due to their exceptional combination of energy efficiency and powerful processing capability. For memory, the BOXER-6406-ADN offers 32GB of DDR5 at a speed of 4800 MHz via the SODIMM slot, enabling high-speed data transfer to its collection of industrially suitable interfaces, such as DB-9 and DB-15 connectors for RS-232/422/485 and digital I/O functionality. In addition, the embedded PCs feature two RJ-45 connectors for Intel® I226-LM Ethernet with 2.5GbE, dual HDMI, and a total of four USB Type-A ports (USB 3.2 Gen 2 x 2, USB 2.0 x 2). Flexible storage options are provided through a 2.5" SATA hard drive and an M.2 2280 M-Key, with additional expansion potential through an M.2 2230 E-Key for Wi-Fi, as well as a full-size mini card and SIM slots.
BRESSNER emphasizes that the BOXER-6406-ADN is precisely tailored to the needs of the smart factory market due to its rugged, compact, and fanless design combined with a variety of high-speed interfaces. The company particularly highlights its suitability for applications such as automated guided vehicles (AGVs), edge gateways, and automated manufacturing.
As a system integrator, manufacturer, value-added distributor, and system house for industrial hardware solutions, components, accessories, and built-to-order solutions, BRESSNER offers an extensive portfolio for various applications in the industrial environment. Tailored solutions for machine automation, logistics & transport, and production are part of the company’s range of services, as well as comprehensive support for topics such as AI applications, machine/deep learning, networks, intelligent retail, communication, and security. The company’s headquarters is located in Germany, with its parent company, One Stop Systems, based in the USA.
