Panel PC in aesthetic design

The 21.5" Panel PC still proves itself with great design. The appealing front is equipped with a Full HD TFT LCD touch display with PCAP touch function. The optional peripheral extensions are kept in an adequate design. This results in an attractive unified front even with a webcam, RFID reader, barcode scanner or SMART Card and magnetic card reader installed. The D210-11TGS series is available with Intel® Tiger Lake Core i3/i5/i7 processor, or with Intel® Celeron® processor. The Celeron® 6305E operates with 2 cores and 2 threads and a base clock speed of 1.80 GHz. The Core™ i3-1115G4E is equipped with 2 cores and 4 threads and has a base clock frequency of 2.20 GHz. The Core™ i5-1145G7E and i7-1185G7E are each equipped with 4 cores and 8 threads. The basic clock frequency of the i5 is 1.5 GHz, that of the i7 1.80 GHz. The RAM of the Panel PC can be equipped with up to 32GB DDR4 RAM. Two 2.5 GbE ports with Intel® I219-LM GbE LAN and Intel® I225-LM 2.5 GbE LAN controller, four USB 3.1 ports and two COM ports are available for network connection and communication. Additional monitors can be connected via the two HDMI ports. Furthermore, the D210-11TGS offers an M.2 3042 B key slot for expansion cards and a 2.5" SATA drive bay for storage. The D210-11TGS can be operated in a semi-industrial temperature range of 0 to 40 °C and a voltage between 8 and 24 volts DC. For mounting, ICP offers suitable feet or VESA wall mounts.

Specifications

• 5" Full HD TFT LCD Panel PC
• Intel® Tiger Lake UP3 Celeron® /Core™ i3/i5/i7
• IP65 Front Panel
• PCAP touch
• 2x 2.5 GbE

Applications

• Display systems
• Info terminals
