SQUARE 18 and SQUARE 21 – Industrial panel PCs

As standard, the two panel PCs are equipped with an Intel® Celeron® 6305E CPU, which can optionally be replaced by an Intel® Core™ i3-1115G4E processor for even more performance. The CPU is supported by up to 32GB DDR4 RAM and an up to 2TB NVMe M.2 SSD. Thanks to the temperature range from 0°C to +50°C, an IP65 certified display and a robust, passively cooled metal housing, the SQUARE 18 and SQUARE 21 have definitely earned the name industrial PC.

2x DisplayPort for 8K resolution and LCD display

The highlight of the SQUARE models is of course the eponymous 10-point multi-touch LCD display. The 18.5” version has a resolution of 1366 x 768 (WXGA) and the 21.5” version has a resolution of 1920 x 1080 (Full HD). Thanks to the integrated Intel® UHD graphics unit and two DisplayPort 1.4, two screens can be controlled and content can be played in a resolution of 7680 x 4320 @ 60Hz – i.e. 8K.

Optional equipment and connections for the PoS

As usual with our industrial PCs, the SQUARE 18 and 21 can also be optionally equipped with Windows 11 Professional and Windows 10 IoT. There is also the option for WiFi. The panel PCs are equipped with a wide variety of connections. In addition to a Gigabit and a 2.5 Gbps LAN port, this also includes four USB 3.2 Gen 2×1 ports and two COM RS232/422/485. The latter enable the connection of external peripherals and thus also use at the point of sale.

The SQUARE 18 and SQUARE 21 models open up a whole new product group in the spo-comm range. The panel PCs are suitable for various areas of application in both industry and kiosks. They are characterized by their robust housings, which are paired with an 18.5” or 21.5” LCD display. From the CPU to the RAM and mass storage, to the WiFi and operating system, the systems can be optimally adapted to the required application. The mini PCs are available now and can be configured and ordered according to your wishes at www.spo-comm.de/en.

Highlights and technical data at a glance:

• CPU: Intel® Celeron® 6305E / Intel® Core™ i3-1115G4E
• GPU: Intel® UHD-Graphics
• RAM: up to 8 GB DDR4 
• SSD: up to 2TB M.2 NVMe
• Max. resolution: 7680 x 4320 @ 60Hz (8K) on two displays
• SQUARE 18 (H x W x D): 286,3mm x 465,2mm x 67,5mm  
• SQUARE 18: 18,5” 10-point multitouch LCD display, resolution 1366 x 768
• SQUARE 21 (H x W x D): 315,5mm x 520,5mm x 67,9 mm  
• SQUARE 21: 21,5” 10-point multitouch LCD display, resolution 1920 x 1080
• IP65 (front) certified
• Ambient conditions: -0°C to +50°C at 10-90% non-condensing humidity 

Connectors: 

• 4x USB 3.2 Gen 2×1
• 2x DisplayPort 1.4
• 1x Gigabit LAN
• 1x 2.5 Gbps Ethernet
• 2x COM RS232 / 422 / 485
• WiFi optional
