On the road to success – Hydro2Motion & Vögtlin Instruments

Application
The student Hydro2Motion team at the Munich University of Applied Sciences relies on the precise flow measurement of gaseous hydrogen. The efficient vehicle developed there is powered by a hydrogen fuel cell stack and an electric motor. The Vögtlin red-y compact is used to measure the flow of hydrogen consumption, which is characterized by its high accuracy and reliability. In addition to the cumulative total flow, the current consumption of the fuel cell stack is also recorded in order to monitor its behavior and optimize the operating strategy of the drive system in a practical manner. The high dynamics of the measuring range and the fast response time also enable the recording of rapid load changes and thus play a decisive role in increasing the efficiency of the drive system.

Challenge
The precise measurement of hydrogen consumption is a challenge due to the volatile nature of the gas and the high safety requirements. Unreliable measurements can lead to miscalculations and falsify results. In addition, the measuring equipment must be robust and stable enough to deliver consistent results even under varying conditions. The red-y compact is also constantly exposed to vibrations while driving.

Solution
The red-y compact flow meter offers the student team a reliable and precise way to measure hydrogen consumption. The MEMS technology of the Vögtlin mass flow meters offers fast response times of 350 ms and the plug & play functionality without warm-up phases improves user productivity.

Mass flow meters compensate for changes in the ambient or gas temperature through automatic temperature compensation, which significantly improves repeatability. The MEMS technology ensures long-term stability without deviations provided that a clean and dry gas supply is used.
Its compact design and the absence of external batteries make it easy to handle and integrate into this type of research project.

Key Features
• High repeatability & reliability: The flow meter ensures precise and consistent  measurements
• Safe & fast control: The flow meter is easy and safe to use
• Compact unit with high-quality components: The device is lightweight and space-saving, ideal  for student projects and mobile applications
• No external power required for total consumption  measurements: The flow meter remains ready for use at all times
