Compact 400W DC-ATX power supply with wide-range input 6-36VDC

Quality and reliability – Made in Germany
Developed and manufactured in Germany, the DC401W meets the highest quality standards. In addition to a carefully thought-out design, Bicker Elektronik consistently uses high-quality components such as polymer aluminum capacitors, which is reflected not least in a particularly long service life of over 10 years.

Versatile fields of application
With an input voltage range of 6 to 36 VDC, the DC401W ensures a reliable and safe power supply for motherboards even in the event of major fluctuations in the supply voltage or when used in mobile on-board power networks (12V/24V). No base load is required at the precisely regulated ATX outputs (+3.3V, +5V, +12V, -12V, +5V standby). In addition, the flexible cable management makes it possible to use customer-specific cable harness solutions. For this purpose, upon request Bicker Elektronik offers an assembly service for the customer’s cable harnesses with individual cable lengths and plug connections.

Reliable compatibility thanks to design according to ATX3.0 specification
The DC401W was designed as an ATX power solution for compact, fanless computer systems. Thanks to the ATX3.0 specification design, the power supply ensures a reliable and stable power supply for current motherboards with the latest Intel® Core™ processors. These CPUs have a highly dynamic power consumption with sometimes extreme jumps in performance within a very short time. Bicker Elektronik explicitly took this into account when developing the DC/DC converter and designed an optimized circuit design that can meet the requirements and offers excellent control stability even at demanding CPU power levels (PL2). In comparison, with a non-optimized converter, the highly dynamic load jumps of the CPU in boost mode can lead to critical voltage drops that are outside the ATX specification and can therefore cause unstable system behavior.

Highly efficient DC/DC converter with fanless contact cooling
With a high efficiency of up to 94% and an optimized thermal design, the DC401W is characterized by high efficiency, minimal heat generation and long-term reliability. A thermal pad on the underside of the circuit board ensures optimum thermal connection of the power components to the housing. This ensures safe and efficient contact cooling.

Availability & design-in advice
The DC401W is available now and can be ordered directly from Bicker in personal B2B contact or conveniently 24/7 in the international web shop at www.bicker.de. The Bicker team is happy to provide further information and individual advice.

All product advantages at a glance

• High power 400W DC/DC converter
• Fanless contact cooling via thermal pad
• Over 10 years polymer capacitor lifetime
• Very compact design in a 1U chassis
• Ultra wide input range 6…36VDC
• ATX output voltage +12 V / 27 A, +5 V / 7 A, +3.3 V / 7 A, –12 V / 0.3 A and 5 Vsb / 3 A
• Excellent control properties
• Full performance in the temperature range -20°…+60°C
• Very high efficiency up to 94%
• Made in Germany

Product link DC401W: https://www.bicker.de/en/dc401w
