NINETEEN Q670E – Industrial server PC with optional Nvidia RTX
Extended temperature range and wide range power input
As the successor to the NINETEEN Q370 from spo-comm, the NINETEEN Q670E has received some upgrades. With its extended temperature range from 0°C to +60°C and a height of 1.5 HE, the Mini-PC can be used perfectly as a server.
The heart of the system is an Intel® Core™ i5 12500T CPU, which is combined with up to 64 GB RAM and an SSD of up to 2 TB.
4x DisplayPort 1.4a up to 4K and Nvidia RTX GPU
The housing of the NINETEEN Q670E with dimensions of 68 x 424 x 298 mm (H x W x D) has many important connections, including 4 DisplayPort 1.4a (with up to 4K video resolution), 10 USB ports and 2 LAN ports. This means that the system can be connected to a wide variety of peripherals in an industrial environment.
The PCIe x16 slot can also be used to connect an optional Nvidia RTX graphics card, which enables applications in the areas of deep learning, machine learning and AI calculations.
Hot Swap SSD, iAMT, Wake on LAN
The NINETEEN Q670E comes with some special features. This includes the ability to install multiple SSDs in a RAID array, which are also hot swappable. The system also supports iAMT and Wake on LAN.
The Mini-PC can optionally be equipped with WiFi or an operating system – depending on requirements. Ubuntu, Windows 11 Pro and Windows 10 IoT are available.
The NINETEEN Q670E is perfect for use as a server PC. With the Intel® Core™ i5 12500T processor, an extended temperature range and many different connections, such as the PCIe slot for installing an additional Nvidia graphics card, the Mini-PC can also be used for machine learning and AI applications. The system is available now and can be configured and ordered according to your wishes at www.spo-comm.de.
Highlights and technical data at a glance:
- CPU: Intel® Core™ i5-12500T (6x 2.0 GHz, max. 4.4 GHz)
- GPU: Intel® UHD-Grafik 770 (integrated)
- GPU: Nvidia RTX A2000 / 2000 / 4000 (optional)
- RAM: up to 64 GB DDR5
- SSD: up to 2TB M.2 NVME / up to 4 TB SATA (RAID 1)
- Max. resolution: 3840 x 2160 @ 60Hz (4K)
- 4 independent displays
- Dimensions (H x W x D): 68 x 424 x 298 mm
- Ambient conditions: -0°C to +60°C at 10-90% non-condensing humidity
Connectors:
- 2x USB 2.0
- 3x USB 3.2 Gen 2
- 4x USB 3.2
- 1x USB Typ C
- 4x DisplayPort 1.4
- 1x 2.5 Gbps LAN
- 1x Gigabit LAN
- 2x Audio (Line-In and Line-Out)
- 1x PCIe x16
- WiFi optional
